CyberPower Systems Switched ePDU 1RU horizontal 12Amp input - SNMP Network Connection - 8x IEC-320 C13 out -IEC-320 C14 in - 2 Yrs Adv. Replacement WTY Features: Real-time Local/Remote Monitoring as well as Switching Work under High Temperature 1% Measurement Accuracy Digital Real-time Load Display Hot-swappable LCD Design LED Status Indicator Supports ENVIROSENSOR PowerPanel Management Software Cord Retention Tray Controllable Receptacles with Power Sequencing Ultra Low Power Consumption Industrial-grade Metal Housing User Configurable Color LCD Rotatable LCD for Proper Display Orientation Firmware Upgrade via USB User-upgradeable Firmware Adjustable Mounting Brackets IEC Receptacle Locking Nominal Input Voltage ( Vac ): 100 - 240 Input Frequency ( Hz ): 50 / 60 Maximum Input Current ( A ): 12 (UL) | 10 (CE) Input Connector Type: IEC C14 x 1 Power Cord Length: 3.05m Output Voltage ( V ): Depends on Input Idle Power Consumption ( W ): < 5 Outlet(s) - Total: 8 Outlet Type: IEC C13 x 8 Remote Individual Outlet Control: Yes LCD Information Display: Input Voltage (Volts), Input Frequency (Hz), Current Level (Amps), Power Consumption (Kilowatts), Network Information, Serial Number, Environment Status, Hardware Version, Firmware Version Hot-swappable LCD Module: Yes Auto LCD Orientation: Yes LCD Setting & Control: Outlet Control, LCD Settings, Reset / Reboot LED Indicators: PDU Status, Tx/Rx, Link, Outlet Outlet Metering Capability: 1% A-type USB Port: Yes Connectivity Port: RJ45, RJ45 (for Serial), RJ45 (for ENVIROSENSOR/ Daisy Chain (In)), RJ45 (for Daisy Chain (Out)) Environmental Sensor Supported: Yes User-upgradeable Firmware: Yes Power Management Software: PowerPanel Business (Recommended for small-medium scale management), PowerPanel Enterprise (Recommended for large scale management) Supported Protocols: IPv4/v6, SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS, Telnet, FTP, and Syslog Authentication: RADIUS, LDAP, LDAPS, Windows AD Installed Rack Height (U): 1 Form Factor: 1U Vertical Rackmount, 1U Horizontal Rackmount Enclosure Construction: Steel Cord Retention Tray: Yes IEC Receptacle Locking: Yes External Site Ground Pin: Yes Adjustable Mounting Brackets: 2 Set (L-short | L-long) Dimensions: 433 x 44 x 112mm Weight: 2.1kg Certifications: CE | FCC Class A | UL60950 | UL62368 | EN 55032 Class A RoHS: Yes
